Small drive roller water-cooled diesel engine
Domestic brand Changchai diesel engine, superior performance, strong power;
The main bearing adopts international brand NSK high-precision ball bearing to ensure the overall performance of the machine;
Two-way hydraulic travel, small operating radius, easy operation, flexible rotation;
product details
Additional Specs
Operating weight
730kg
Total length
1880mm
Total width
860mm
Total height (excluding anti-collision beam)
1250mm
Vibration form
One-button vibration-electromagnetic clutch
Engine optional (National II/National IV/EPA/Euro V)
Changfa 178/Honda GX270/Changchai R180/Kep 178/Brigley & Stratton Other engines can be consulted separately
Compact design and scene adaptability
Narrow space passability:
– The body width is usually ≤1m meters, which can enter small construction sites, rural roads or courtyards. – Articulated steering design, minimum turning radius ≤3 meters, suitable for “Z” shaped compaction path.Complex terrain capability:
– Climbing ability ≤25°, equipped with anti-skid steel wheels or optional bump wheels, suitable for muddy and loose bases. – Ground clearance ≥20cm, can cross small trenches or gravel piles.
Continuous operation advantage of water-cooled engine
Efficient heat dissipation capacity: – The water cooling system stabilizes the temperature by circulating coolant (operating temperature fluctuation ≤5℃), ensuring the continuous and efficient operation of the engine in an environment of -30℃ to 50℃, and avoiding the power attenuation of air-cooled models under extreme high temperatures (the power reduction of air-cooled high temperature can reach 15%-20%).
– Suitable for high temperature scenes such as asphalt pavement final pressure, and can operate continuously for 8 hours without stopping for cooling.
